DOC. NO. 5956.573.05 P. 5 6 / 8 8
WTM300S PROG 016
1. GENERIC FUNC. Enter GENERIC FUNC. and set the following parameters.
Set default par. Yes / 1 Sets all parameters to their default value.
2. Switch the machine off and then on again.
3. GENERIC FUNC. Enter GENERIC FUNC. and set the following parameters.
Appl. type Pw Ws Ri / 1 Type of machine: Without Dt
Pw Ws Ri Dt / 2
Type of machine: With Dt
Appl. direct. Left / 0 Rack feed direction: Left
Right / 1 Rack feed direction: Right
Speed nr. 1 60 Indicates feed gear motor operation frequency at speed 1 [Hz].
Wash time sp 1 100 Time from when the last rack releases the auto start lever until the wash
pumps stop when speed 1 [s] is set.
Speed nr. 2 100 Indicates feed gear motor operation frequency at speed 2 [Hz].
Wash time sp 2 60 Time from when the last rack releases the auto start lever until the wash
pumps stop when speed 2 [s] is set.
Drain enable 63 Enable draining and cleaning cycles.
Heat two comm. No / 0 Wash tank heating element management.
Heating manage High / 0 Machine heating power management.
Boiler load tank No / 0 The tank is filled by means of a dedicated solenoid valve.
Fahrenheit vis. Unit of measure used in displaying the temperatures; if set to “Yes” the
temperature is displayed in degrees Fahrenheit, otherwise in degrees
Celsius
No / 0 Celsius visualization
Yes / 1 Fahrenheit visualization
Rinse autostart Indicates the type of rinse stage control.
Software / 0 Up to serial number 71800000
Mechanical / 1 From serial number 71800001
Max motor curr. see par. A4.8 Indicates the max. current deliverable to the gear motor by the inverter.
Nsf settings No / 0 Duo and tank temperature standard setting.
4. RINSE MODULE Enter RINSE MODULE and set the following parameters.
Boil. temp. start 82 Boiler temperature set point at start of rinse stage.
Boiler temper. 82 Boiler temperature set point.
Boiler temper warmup 70 Boiler warm-up temperature.
Delta T stand-by 5 Boiler temperature decrease during standby.
First boil. temp. 59 First USA compact boiler temperature set point.
Duo temper. 70 Tank temperature set point.
Hist. duo temp. 5 Tank hysteresis temperature.
Drain del. airgap
32 Time from reaching level 0 (level in air trap) in the air gap, to stopping of
the rinse pump.
Duo heat. unrel. Yes / 1 Enables activation of the DUO heating element even if the tank and
boiler heating elements are on.
5. WASH MODULE Enter WASH MODULE and set the following parameters.
Wash module 1490 / 1 Type of wash module.
Tank te mper. 66 Tank temperature set point.
Histeresys temp. 2 Tank hysteresis temperature.
Condensing unit No / 0 Without CU
Yes / 1 With CU
Wash temp. ready 64 Wash tank “warmup end” temperature.
6. PREWASH MODULE Enter PREWASH MODULE and set the following parameters.
Prewash module 1490 / 1 Type of prewash module.
Standby level 205 Indicates the max. level in prewash tank.
Run level 170 Indicates the max. prewash tank level when the prewash pumps are
working.
7. DT MODULE Enter DT MODULE and set the following parameters.
DT temper 70 Drying tunnel temperature set point.
DT type Standard / 0 Indicates the type of DT installed.
8. Switch the machine off and then on again.
