7 RIGHT SIDE BROOM SPRAY WATER
ON / OFF - Turns the spray water at the right
side broom and main broom on and off.
8 RIGHT SIDE BROOM LIGHT ON /
OFF - Turns the light at the right side broom
on and off.
9 LEFT SIDE BROOM PRESSURE
REGULATOR - Regulates the downward
pressure on the left side broom. Lift locking
knob and turn to adjust. Push down on locking
knob to lock at desired pressure setting.
10 COOLANT TEMPERATURE GAUGE -
Indicates the temperature of the engine
coolant. If the needle nears the highest tem-
perature, stop and check the level of the
coolant.
11 TACHOMETER/HOUR METER -
Indicates the speed of the engine in thousands
of revolutions per minute (rpm). After initial
start-up idling, hour meter records engine run-
ning hours.
12 OIL PRESSURE GAUGE - Indicates
engine oil pressure. If the needle indicates low
oil pressure, stop and check the oil level.
13 RIGHT SIDE BROOM PRESSURE
REGULATOR - Regulates the downward
pressure on the right side broom. Lift locking
knob and turn to adjust. Push down on locking
knob to lock at desired pressure setting.
14 STEERING CIRCUIT CONTROL -
Switches the dualized chassis steering from
left to right.
15 CHASSIS ENGINE IGNITION - See
Operator’s Manual for truck chassis.
16 AUXILIARY ENGINE RUN LIGHT -
When on, indicates that the auxiliary engine is
running.
O-3
OPERATION
