17 AUXILIARY ENGINE IGNITION -
Turns the auxiliary engine, which powers the
sweeping functions, on and off.
18 MAIN BROOM PRESSURE REGULA-
TOR - Regulates the downward pressure on
the main broom. Lift locking knob and turn to
adjust. Push down on locking knob to to lock at
desired pressure setting.
19 SWEEP/TRANSPORT CIRCUIT
SELECT - Switches the sweeper from sweep
to transport mode.
20 BEACON LIGHT ON/OFF (Optional)
- Turns the optional beacon light on and off.
21 FLOODLIGHT ON/OFF - Turns the
floodlight on and off. The right hand rear
floodlight is standard. An optional Left hand
floodlight is available.
22 HYDRAULIC FILTER RESTRICTION
INDICATOR - Indicates that the return filter
at the hydraulic fluid reservoir is clogged and
in need of service.
23 TILT WARNING INDICATOR -
Indicates that the machine is not level. If this
light is on, the hopper must NOT be raised.
24 CONVEYOR UP/DOWN - Controls the
lowering and raising of the conveyor. Pressing
forward on the switch puts the conveyor and
dirt shoes into sweep position. Pressing rear-
ward raises conveyor and dirt shoes to trans-
port position.
25 MAIN BROOM UP / DOWN / ROTATE
- Controls the raising, lowering and rotation of
the main broom. Pressing forward on switch
will lower and rotate the main broom. Pressing
rearward will raise broom and stop rotation.
OPERATION
O-4
