26 CONVEYOR ROTATE ON/OFF -
Controls the rotation of the conveyor, both for-
ward and reverse. Pressing forward will rotate
conveyor forward. Pressing rearward will
rotate conveyor rearward.
27 HOPPER UP/DOWN (F-Series Only)-
Raises and lowers the hopper. Press forward
on switch to raise hopper until desired position
is reached. Press rearward to lower hopper.
28 HOPPER DUMP - Causes the hopper to
dump and to roll back to normal position.
Pressing forward will open hopper door and
tilt the hopper. Pressing rearward will roll
back the hopper and close hopper door.
29 AIR FILTER RESTRICTION INDICA-
TOR - Indicates that the engine air filter is
clogged and in need of service.
30 HOPPER UP INDICATOR - Indicates
that the hopper is in a raised position.
31 NO SPRAY WATER INDICATOR -
Indicates that the supply in the water tank
has been completely used up. Fill water tank
to turn off indicator.
32 HOPPER FULL INDICATOR -
Indicates that the hopper has reached its max-
imum weight limit.
33 SPRAY WATER FLOW - A three-way
switch that controls the volume of water
used..Can be set for Low, Medium or High
34 SHUTDOWN OVERRIDE (optional) -
Automatic engine shutdown protects against
damage from high coolant temperature, low
engine oil pressure or low hydraulic oil level.
To start an engine with this feature, depress
this switch while starting the engine.
35 MAIN BROOM AIR PRESSURE
GAUGE - Indicates digging pressure of the
main broom. A lower pressure indicates
O-5
OPERATION
