• panel drilling 29x71 mm;
• integrated fan speed control up to 2A maximum without CF
additional module.
• PWM
• MODBUS communication protocol
• Antifreeze function with heat pump
• Adaptive Function
• Fan Defrosting
Ech 215 BD MW320040
The same as ECH 210BD except for:
• 5 internal relays with ONLY ON/OFF condensation fan speed
management.
FRONTAL PROTECTION PR111120 Rubber frontal sheath for high protection from external environment.
CF-05 MODULE MW991000
Open board (back-of-board mounting) for fan speed control (for fans
with current higher than 2A) through phase cut.
Characteristics of the model:
• power 500W;
• Faston connectors.
CF-15 MODULE MW991100
Open board (back-of-board mounting) for fan speed control (for fans
with current higher than 2A) through phase cut.
Characteristics of the model:
• power 1500W;
• Faston connectors.
CF-22 MODULE MW991200
Open board (back-of-board mounting) for fan speed control (for fans
with current higher than 2A) through phase cut.
Characteristics of the model:
• power 2200W;
• Faston connectors.
CF-REL MODULE MW991300
Open board for the condensation fan ON-OFF control.
Characteristics of the model:
• maximum current 6A.;
• faston connectors.
ECH 211 EXP MW320100
Relay module (230V~, 10A) with DIN guide mounting base for heat
pump step 2 control. To be used in heat pump 2 steps configurations
together with ECH 211.
KEYBOARD TS-W ECH 200 MW320600 Keyboard for remote machine control for wall mounting.
KEYBOARD TS-W/ND ECH 200 MW320601 Keyboard for remote machine control for wall mounting without display.
KEYBOARD TS-W/S ECH 200 MW320602
Keyboard for remote machine control for wall mounting with internal
temperature sensor.
TRANSFORMER TF411200 Transformer 230V~/12A 5,6VA
COPY CARD MW320500 Parameter scheduling key (for hard storage device parameters)
COHV0100 Harness for user control (connector + 1 m cables).
COLV0100
Harness (connector + 1 m cables) to connect low voltage inputs and
outputs.
CORK0100(*)
3-way harness (connector + 1 m cables) for:
• TS-W ECH 200;
• ECH 210A.
ELECTRICAL WIRING
COER0100(*)
2-way harness (connector + 1 m cables) for:
• ECH 211 EXP.
FILTER FT111201 LC mains filter for ECH 200.
SN691150 Temperature probe NTC 103AT 1,5MT .
SN8P2X1502 Temperature probe NTC 103AT 1,5MT rapid.
SN8S0A1500 Temperature probe NTC 6X40 1.5 MT SILICONE.
PROBE
SN8S0A3000 Temperature probe NTC 6X40 3 MT SILICONE.
EWRS485 T6V53C0700 Serial interface module RS485-TTL for mounting on DIN/4 guide
PARAM MANAGER SPPM000100
Scheduling software for Invensys instruments in WINDOWS environment
(with EWTK-PT only).
EWTK-PT T6V51C0750
Interface module for PARAM MANAGER (RS232 - TTL/RS485) software
for mounting on DIN/4 guide.
EWTK-NET T6V51C0760
Serial Interface Module with Invensys protocol (RS232 - TTL/RS485) for
mounting on DIN/4 guide.
MULTI NETWORK INTERFACE MW318933
Passive serial interface module for mounting on DIN/4 guide.
• RS232-TTL
• RS232-RS485
• TTL-RS485
RS 232 cable 1500128 1,8 m length (**)
TTL cable 1500180 0,3 m (30 cm) length (***)
((*) These electrical harnesses are already provided in the instrument package they are to be connected with.
(**) Other lengths available. Recommended 1,8 m. Maximum length depends on transmission data speed
(***) Other lengths available. Recommended 0,3 m. Other lengths allowed due to magnetic disturbance in environment .
GENERAL NOTES:
• COHV e COLV harnesses are not necessary if directly made up by the manufacturer.
• Remote keyboard connections through 3-way harness without using optional modules.
• Invensys also has multiple NTC probes with different kind of cables (PVC or silicone) and different cable lenght.
