(((ELKRON))) - MP110
00 - Station opening tamper
01 - Station input 1 or input tamper (for double balancing)
02 - Station input 2 or input tamper (for double balancing)
03 - Station input 3 or input tamper (for double balancing)
04 - Station input 4 or input tamper (for double balancing)
05 - Station input 5 or input tamper (for double balancing)
06 - Station input 6 or input tamper (for double balancing)
07 - Station input 7 or input tamper (for double balancing)
08 - Station input 8 or input tamper (for double balancing)
09 - Station 24 h input or input tamper (for double balancing)
10 - Tamper expansion 1
11 - Input 1 expansion 1 or input tamper (for double balancing)
12 - Input 2 expansion 1 or input tamper (for double balancing)
13 - Input 3 expansion 1 or input tamper (for double balancing)
14 - Input 4 expansion 1 or input tamper (for double balancing)
15 - Input 5 expansion 1 or input tamper (for double balancing)
16 - Input 6 expansion 1 or input tamper (for double balancing)
17 - Input 7 expansion 1 or input tamper (for double balancing)
18 - Input 8 expansion 1 or input tamper (for double balancing)
19 - Input 24h expansion 1
1A - Auxiliary input expansion 1
20 - Tamper expansion 2
21 - Input 1 expansion 2 or input tamper (for double balancing)
22 - Input 2 expansion 2 or input tamper (for double balancing)
23 - Input 3 expansion 2 or input tamper (for double balancing)
24 - Input 4 expansion 2 or input tamper (for double balancing)
25 - Input 5 expansion 2 or input tamper (for double balancing)
26 - Input 6 expansion 2 or input tamper (for double balancing)
27 - Input 7 expansion 2 or input tamper (for double balancing)
28 - Input 8 expansion 2 or input tamper (for double balancing)
29 - Input 24h expansion 2
2A - Auxiliary input expansion 2
30 - Tamper expansion 3
31 - Input 1 expansion 3 or input tamper (for double balancing)
32 - Input 2 expansion 3 or input tamper (for double balancing)
33 - Input 3 expansion 3 or input tamper (for double balancing)
34 - Input 4 expansion 3 or input tamper (for double balancing)
35 - Input 5 expansion 3 or input tamper (for double balancing)
36 - Input 6 expansion 3 or input tamper (for double balancing)
37 - Input 7 expansion 3 or input tamper (for double balancing)
38 - Input 8 expansion 3 or input tamper (for double balancing)
39 - Input 24h expansion 3
3A - Auxiliary input expansion 3
40 - Tamper expansion 4
41 - Input 1 expansion 4 or input tamper (for double balancing)
42 - Input 2 expansion 4 or input tamper (for double balancing)
43 - Input 3 expansion 4 or input tamper (for double balancing)
44 - Input 4 expansion 4 or input tamper (for double balancing)
45 - Input 5 expansion 4 or input tamper (for double balancing)
46 - Input 6 expansion 4 or input tamper (for double balancing)
47 - Input 7 expansion 4 or input tamper (for double balancing)
48 - Input 8 expansion 4 or input tamper (for double balancing)
49 - Input 24h expansion 4
4A - Auxiliary input expansion 4
A1 - Input 1 READER 1
A2 - Input 2 READER 1
A3 - Input 1 READER 2
A4 - Input 2 READER 2
A5 - Input 1 READER 3
A6 - Input 2 READER 3
A7 - Input 1 READER 4
A8 - Input 2 READER 4
B1 - Input 1 keyboard 1
B2 - Input 2 keyboard 1
B3 - Input 1 keyboard 2
B4 - Input 2 keyboard 2
B5 - Input 1 keyboard 3
B6 - Input 2 keyboard 3
B7 - Input 1 keyboard 4
B8 - Input 2 keyboard 4
Input
Coding
Table
2.4 Inputs
The number of every input
consists of 2 digits.
The left side digit identifies
the group, the right side digit
identifies the group input
number
Example: 1 7
Expansion 1
Input 7
BA - tamper keyboard 1
BB - tamper keyboard 2
BC - tamper keyboard 3
BD - tamper keyboard 4
11
