Elma Elmasonic Select - Elmasonic Select 150-300 Specifications

Elma Schmidbauer GmbH 5 Technical data
Elmasonic Select 11 / 32
Performance data
Total power consumption W 750 550 1,000
Effective ultrasonic power ±10% W 150 150 200
Peak ultrasonic output max. W 600 600 800
Heating power W 600 400 800
5.3 Elmasonic Select 150–300
Elmasonic Select Unit 150 180 300
Mechanical data
Max. external dimensions W/D/H
(unit with cover)
mm 575/360/230 405/360/330 575/360/330
Interior dimensions W/D (tank
below fill level marking)
mm 485/280 300/370 475/270
Fill level (tank base to fill level
marking)
mm 65 165 165
Working height (basket base to fill
level marking)
mm 35 130 135
Recommended tank operating
capacity
L 8.7 14.2 22
Weight (unit with cover) kg 8.8 10.2 12.2
Performance data
Total power consumption W 1,100 1,000 1,500
Effective ultrasonic power ±10% W 300 200 300
Peak ultrasonic output max. W 1,200 800 1,200
Heating power W 800 800 1,200
