5 Technical data Elma Schmidbauer GmbH
12 / 32 Elmasonic Select
5.4 Elmasonic Select 500/900
Elmasonic Select Unit 500 900
Mechanical data
Max. external dimensions W/D/H (unit with
cover)
mm 770/425/505 870/595/505
Max. external dimensions W/D/H (unit with
sound-protection cover)
mm 770/510/975 870/640/1,145
Interior dimensions W/D (tank below fill level
marking)
mm 500/330 600/500
Fill level (tank base to fill level marking) mm 235 200
Working height (basket base to fill level
marking)
mm 220 190
Recommended tank operating capacity L 40.3 63.7
Weight (unit with cover) kg 30.4 43.4
Weight (unit with sound-protection cover) kg 34.7 49.3
Weight (filled unit with cover) kg 70.1 106.7
Weight (filled unit with sound-protection
cover)
kg 74.7 112.5
Performance data
Total power consumption W 2,080 2,960
Effective ultrasonic power ±10% W 480 960
Peak ultrasonic output max. W 1,920 3,840
Heating power W 1,600 2,000
