Elma Elmasonic Select - Controls Overview

8 Controls Elma Schmidbauer GmbH
16 / 32 Elmasonic Select
8 Controls
1
2 3 4
5
678
9
10
Illustration4: Controls
1 Cleaning duration display value/unit/symbol
2 Current ultrasound mode display name/bar element
3 Start/stop button for ultrasonic cleaning (short press)/ultrasonic cleaning with temperature-
controlled start (long press)
4 Temperature display value/unit/symbol
5 Plus/minus buttons set temperature/programme memory/parameter values (short press),
quick cycle (long press)
6 Select button to switch between programme mode and normal mode (short press)/save
program (long press)
7 On/off button switch unit on/off
8 Mode button to set ultrasound mode (short press)/ultrasonic cleaning with auto-degas (long
press)
9 Plus/minus buttons set cleaning duration/programme memory/parameters
10 Display showing all LED indicators for LED test
