8.1 Ultrasound mode display
The display shows the currently set ultrasound mode by displaying the mode name and a certain
number of bar segments. You can choose from the following ultrasound modes:
degas
(0 segments)
auto-degas
(degas
flashing)
Used to degas cleaning fluid and for specialist laboratory applications.
Used to degas the cleaning fluid before ultrasonic cleaning. The set
ultrasound mode starts automatically once degassing has been
completed (duration approx. 10min.).
eco
(1 segment)
Used for gentle cleaning and quieter operation. The sweep ultrasound
mode is a lower-intensity cycle.
sweep
(2 segments)
This mode performs most cleaning tasks with an evenly distributed sound
field (standard ultrasound mode).
pulse
(3 segments)
Removes stubborn dirt using pulsed sound field distribution.
dynamic
(4 segments)
Combines the ultrasound modes sweep and pulse to improve the overall
cleaning power.
8.2 Operating status symbols
The following symbols are shown on the display as soon as the unit enters the respective operating
status:
End of
cleaning
Ultrasonic cleaning has been completed and is finished.
Remaining
time
Ultrasonic cleaning is running; the remaining cleaning duration is
shown below the symbol.
Dry operation
(Not available for Elmasonic Select500/900).
The tank is empty, or the filling level is too low. Dry-run detection
is available during active heating.
Setup
Setup mode is activated; the unit parameters [}27] can be
changed.
Heating The ultrasonic bath is currently being heated.
Temperature-
controlled
start
Ultrasonic cleaning will start automatically as soon as the set
cleaning temperature has been reached.
Temperature
limit
A temperature limit is defined as a maximum permissible cleaning
temperature. A higher temperature cannot be set.
The symbol flashes as soon as the temperature limit is reached or
exceeded.
..
Programme
The displayed cleaning programme is selected (programme
number 1–4). A total of fourcleaning programmes can be stored.
