Elma Elmasonic Select - Unit Description

Elma Schmidbauer GmbH 7 Unit description
Elmasonic Select 15 / 32
7 Unit description
1
2
3
56
7
89
10
4
Illustration2: Operating side/rear side
1 Warning of hot surfaces 7 Rotary switch, open/close drain
2 Display, splash-proof 8 Feet, non-slip
3 Handle 9 Membrane keyboard, wipeable
4 Mains connection 10 Blower on the unit base (not shown) (not
available for Elmasonic Select 30–100)
5 Nameplate, not shown 11 Ball valve, open/close drain (Elmasonic Select
500/900)
6 Drain (not available for Elmasonic
Select 30/40/500/900)
11
Illustration3: Drain of Elmasonic Select 500/900
