Parameter reference:
The following unit functions can be adjusted. The preset factory values are shown in bold:
Parameter Unit function Value Effect
01 *
Adjustment range for
cleaning duration
>10min.
00/01
Increments of5min./increments of
1min. (as for cleaning durations up
to10min.). NOTICE!Saved
programmes will be deleted.
02
Show remaining time
<1min. in seconds
00/01 Off/on
03 * Temperature unit °C/°F
Display in degrees Celsius/
Fahrenheit. NOTICE!Saved
programmes will be deleted.
04 * Default temperature limit
00/40/45/50/55/60
00/100/110/120/130/
140
Off/40°C/45°C/50°C/55°C/60°C
Off/100°F/110°F/120°F/130°F/140°
F NOTICE!Saved programmes will
be deleted.
05
Acoustic signal for “End
of cleaning”
00/01/02 Off/melody1/melody2
06
Acoustic signal for “Error
message”
00/01/02 Off/melody1/melody2
07
Acoustic signal for
“Temperature limit
exceeded”
00/01/02 Off/melody1/melody2
08
Response if temperature
limit is exceeded
00/01/02/03
No action/ultrasound off/heating off/
ultrasound and heating off
09 Display brightness 01/02/03/04 Dim/medium/normal/bright
10 LED test 00/01
Off/all display LEDs on for approx.
5sec.
20 ***
Autostart on restoration
of power supply
00/11/12/13
Off/ultrasound on/heating on/
ultrasound and heating on
CAUTION!Risk of damage to the
unit if the unit runs dry.
30 * Reset unit settings 00/11
Off/on: "11" resets all settings to the
factory settings. NOTICE!Saved
programmes will be deleted.
31 **
Response if dry-run
monitor is triggered
00/01
No action/ultrasound and heating
off, display Dry run symbol.
** Not available for unit sizes 500/900.
*** The unit starts up immediately in heating and/or ultrasound operation when plugged in or when the
power supply is switched on.
