ELTEX MES53xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 114
Command line prompt in the global configuration mode:
console(config)#
Table 5.104 – List of the global configuration mode commands
Command
Value
Action
multicast snooping
profileprofile_name
profile_name : (1..32)
symbols
Proceed to the multicast profile configuration mode.
no multicast snooping
profile profile_name
Delete the specified multicast profile.
Multicast profile can be deleted only after it will be
unbound from all the switch ports.
Commands for multicast profile configuration mode
Command line prompt in the multicast configuration mode is as follows:
console(config-mc-profile)#
Table 5.105 – List of the commands for multicast profile configuration mode
Command
Value
Action
match iplow_ip [high_ip]
low_ip: valid multicast-
address;
high_ip: valid multicast-
address
Set the profile matchings to the specified range of the IPv4
multicast addresses.
no match iplow_ip [high_ip]
Delete the match of the profile to the specified range of the
IPv4 multicast addresses
match ipv6low_ipv6
[high_ipv6]
low_ipv6: valid IPv6
multicast address;
high_ipv6: valid IPv6
multicast-address
Set the match of the profile to the specified range of the IPv6
multicast addresses.
no match ipv6low_ipv6
[high_ipv6]
Delete the match to the specified range of the IPv6 multicast
addresses.
permit
-/no permit
IGMP-reports will be missed if IGMP reports are not matched
to one of the specified ranges.
no permit
IGMP-reports will be dropped if IGMP reports are not matched
to one of the specified ranges.
Ethernet interface (interfaces range) configuration mode commands
Command line prompt in the interface configuration mode is as follows:
console(config-if)#
Table 5.106 – Commands of the Ethernet interface configuration mode (interfaces range)
Command
Value/Default value
Action
multicast snooping max-
groups number
number (1..1000)/-
Limit the number of simultaneously viewed multicast groups
for interface.
no multicast snooping
max-groups
Remove restriction for the number of simultaneously viewed
groups for interface.
multicast snooping add
profille_name
profile name: (1..32
symbols)
Bind the specified multicast profile to the interface.
multicast snooping remove
{profille_name|all}
Delete the match of multicast profile (or all multicast profiles)
to interface.
EXEC mode commands
All commands are available to the privileged user only.
Command line prompt in the EXEC mode is as follows:
console#
