ELTEX MES53xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 94
no sub-ring vlanvlan_id
Delete the subring.
timer guard value
value:(10..2000) ms,
multiple of 10/500 ms
Set a timer blocking stale R-APS messages.
no timer guard
Set the default value.
timer holdoff value
value:(0..10000) ms,
multiple of 100 to the
nearest 5 ms/0 ms
Set a delay timer of a switch response to changing its status.
Instead of the response to event, timer enables. When the
timer expires the switch will inform about its status. This timer
is assigned to reduce packet flood in case of port flapping.
no timer holdoff
Set the default value.
timer wtr value
value:(1..12) minute/5
minute.
Set the timer which is launched on the RPL Owner Switch in
the revertive mode. It is used to prevent frequent recovery
switching caused by fault signals.
no timer wtr
Set the default value.
switch forced {west | east}
-/no
Force the launch of the secure ring switching at the same time
another port is blocked.
no switch forced
Cancel the forcing of the ring switching.
switch manual {west | east}
-/no
Block/unblock the specified west(east) port manually.
no switch manual
Cancel the manual blocking.
abort
-
Roll back changes made since the moment of the entering in
the ring configuration mode.
EXEC command mode
Command line prompt in the EXEC mode is as follows:
console#
Table 5.82 – EXEC mode commands
Command
Value
Action
show erps [vlanvlan_id]
vlan_id: (1..4094)
Request information about general ERPS status or status of
the specified ring.
5.16.7 LLDP configuration
The main function of Link Layer Discovery Protocol (LLDP) is the exchange of information about
status and specifications between network devices. Information that LLDP gathers is stored on devices
and can be requested by the master computer via SNMP. Thus, the master computer can model the
network topology based on this information.
The switches support transmission of both standard and optional parameters, such as:
 device name and description;
 port name and description;
 MAC/PHY information;
 etc.
Global configuration mode commands
Command line prompt in the global configuration mode is as follows:
console(config)#
Table 5.83. Global configuration mode commands
Command
Value/Default value
Action
lldp run
-/enabled
Enable the switch to use LLDP.
no lldp run
Disable the switch to use LLDP.
lldp timer seconds
seconds: (5..32768)/30
seconds
Specify how frequently the device will send LLDP information
updates.
no lldp timer
Set the default value.
lldp hold-multiplier number
number: (2..10)/4
Specify the amount of time for the receiver to keep LLDP
