ELTEX MES53xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 27
Table 2.20. System indicator LED
LED name
LED function
LED State
Device State
Power
Power supply status
Off
Power is off
Solid green
Power is on, normal device
operation
Flashing green
Power-on self-test (POST)
Master
Indicates master
stack unit
Solid green
The device is a stack master
Off
The device is not a stack
master or stacking mode is
not set
Fan
Cooling fan status
Solid green
All fans are operational
Solid red
One or more fans failed
RPS
Backup power supply
operation mode
Solid green
Backup power supply is
connected and in normal
operation
Solid red
Backup power supply is
missing or failed.
Off
Backup power supply is not
connected
Battery
(MES2324B,
MES2324FB,
MES2348B)
Battery status LED
Solid green
Battery connected, power
good
Flashing green
Battery charging
Solid orange
Main power disconnected,
battery discharging
Flashing red-green
Low battery
Solid red
Battery disconnected
Flashing red
Current release fault
2.6 Delivery Package
The standard delivery package includes:
– Ethernet switch;
– Power module PM75-48/12 or PM-160-220/12;
– Power cable (if equipped with 220V power supply)
– Rack mounting set;
– Documentation.
SFP/SFP+ transceivers may be included in the delivery package on request.
