ELTEX MES53xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 71
console(config-ip)#
This mode is available from the configuration mode and designed for configuration of IP interface
parameters.
Table 5.37. – IP interface configuration mode commands
Command
Value/Default value
Action
directed-broadcast
-/disabled
Enable IP directed-broadcast packet translation into standard
broadcast packet and enable its transmission via the selected
interface.
no directed-broadcast
Disable IP directed-broadcast packet translation.
helper-address ip_address
ip_address: A.B.C.D
Enable forwarding of broadcast UDP packets to the specific
address.
- ip_address - destination IP address for packets forwarding.
no helper-address
ip_address
Disable forwarding of broadcast UDP packages.
Examples of command usage
 Enable the directed-broadcast function:
console# configure
console(config)#interface PortChannel 1
console(config-if)#ip address 100.0.0.1 /24
console(config-if)#exit
console(config)# interface ip 100.0.0.1
console(config-ip)#directed-broadcast
5.10 Selective Q-in-Q
This function uses configured filtering rules based on internal VLAN numbers (Customer VLAN) to
add and external SPVLAN (Service Provider's VLAN), substitute Customer VLAN, and block traffic.
A list of traffic processing rules is created for the device.
Ethernet and Port-Channel interface (interface range) configuration mode commands
Command line prompt in the configuration interface configuration mode is as follows:
console# configure
console(config)# interface {gigabitethernet gi_port | tengigabitethernet
te_port | fortygigabitethernet fo_port | oob | port-channel group | range
{…}}
console(config-if)#
Table 5.38. - Ethernet interface (interface range) configuration mode commands
Command
Value/Default value
Action
selective-qinq list ingress
add_vlan vlan_id
[ingress_vlan
ingress_vlan_id]
vlan_id: (1..4094)
ingress_vlan_id: (1..4094)
Create a rule that will add the second stamp vlan_id to a
packet with the outer stamp ingress_vlan_id. If
ingress_vlan_id is not specified, the rule will be applied to all
ingress packets that are not processed by other rules ('default
rule').
selective-qinq list ingress
deny [ingress_vlan
ingress_vlan_id]
ingress_vlan_id: (1..4094)
Create a ‘deny’ rule to drop tag ingress packets with the
ingress_vlan_id outer tag. If ingress_vlan_idis not set, all
ingress packets will be dropped.
selective-qinq list ingress
permit [ingress_vlan
ingress_vlan_id]
ingress_vlan_id: (1..4094)
Creates a ‘permit’ rule to transmit all ingress packets with the
ingress_vlan_id outer tag. If ingress_vlan_id is not set, all
ingress packets will be transmitted without changes.
