MES53xx, MES33xx, MES23xx Ethernet Switch Series 177
offset_list_name
The name of the user
templates list
Specify the user templates list that will be used to recognize
packets. Every ACL may have its own templates list.
ace-priority
Record priority
The index indicates position of the rule in a list and its priority.
The lower the index, the higher the priority. Possible values
are from 1 to 2,147,483,647.
In order to select the complete range of parameters except dscp and ip-precedence, use

As soon as at least one entry has been added to the ACL, the last entry is set by default to

Table 5.205. Configuration commands for IP-based ACLs
Command
Action
permit protocol {any | source source_wildcard}
{any | destination destination_wildcard}
[dscp dscp | precedence precedence]
 time_name] [ace-priority index]
Add a permit filtering entry for a protocol. The packets that meet the
entry's conditions will be processed by the switch.
permit ip {any | source_ip source_ip_wildcard}
{any | destination_ip destination_ip_wildcard}
[dscp dscp | precedence precedence]
 range_name] [ace-priority index]
Add a permit filtering entry for the IP. The packets that meet the entry's
conditions will be processed by the switch.
permit icmp {any | source source_wildcard}
{any | destination destination_wildcard}
{any | icmp_type} {any | icmp_code}
[dscp dscp | ip-precedence precedence]
 time_name] [ace-priority index]
[offset-list offset_list_name] [vlan vlan_id]
Add a permit filtering entry for the ICMP. The packets that meet the
entry's conditions will be processed by the switch.
permit igmp {any | source source_wildcard}
{any | destination destination_wildcard}
[igmp_type]
[dscp dscp | precedence precedence]
time_nameindex]
Add a permit filtering entry for the IGMP. The packets that meet the
entry's conditions will be processed by the switch.
permit tcp {any | source source_wildcard}
{any | source_port}
{any | destination destination_wildcard}
{any | destination_port}
[dscp dscp | precedence precedence]
 list_of_flags] [time-range time_name]
index]
Add a permit filtering entry for the TCP. The packets that meet the entry's
conditions will be processed by the switch.
permit udp{any |source source_wildcard}
{any | source_port}
{any | destination destination_wildcard}
{any | destination_port}
[dscp dscp | precedence precedence]
time_name] [ace-priority index]
Add a permit filtering entry for the UDP. The packets that meet the
entry's conditions will be processed by the switch.
deny protocol {any | source source_wildcard}
{any | destination destination_wildcard}
[dscp dscp| precedence precedence
time_name]  | [ace-
priority index]
Add a deny filtering entry for a protocol. The packets that meet the
entry's conditions will be blocked by the switch. If the disable-port
keyword is specified, the physical interface receiving the packet will be
disabled. If the log-input keyword is specified, a message will be sent to
the system log.
deny ip {any | source_ip source_ip_wildcard}
{any | destination_ip destination_ip_wildcard}
[dscp dscp | precedence precedence]
range_name]
 | [ace-priority index]
Add a deny filtering entry for the IP. The packets that meet the entry's
conditions will be blocked by the switch. If the disable-port keyword is
specified, the physical interface receiving the packet will be disabled. If
the log-input keyword is specified, a message will be sent to the system
log.
deny icmp {any | source source_wildcard}
{any | destination destination_wildcard}
{any | icmp_type} {any | icmp_code}
[dscp dscp | precedence precedence]
time_name]
Add a deny filtering entry for the ICMP. The packets that meet the entry's
conditions will be blocked by the switch. If the disable-port keyword is
specified, the physical interface receiving the packet will be disabled. If
the log-input keyword is specified, a message will be sent to the system
log.
