MES53xx, MES33xx, MES23xx Ethernet Switch Series 150
Show power supply status for all the device interfaces:
console# show power inline
Power-limit mode: Class based
Usage threshold: 95%
Trap: Disable
Legacy Mode: Disable
Inrush Test: Disable
SW Version: 22.172.3
Unit Module Nominal Consumed Temp (C)
Power (W) Power (W)
---- ------------ --------- ---------- --------
1 MES2308P 240 219 (91%) 85
12-port 1G
Managed
Switch with
8 POE+ ports
2 MES2308P 240 0 (0%) 42
12-port 1G
Managed
Switch with
8 POE+ ports
Interface Admin Oper Power (W) Class Device Priority
---------- ---------- ----------- ----------------- ----- -------------- --------
gi1/0/1 Auto On 31.800 4 low
gi1/0/2 Auto On 31.800 4 low
gi1/0/3 Auto On 31.0 4 low
gi1/0/4 Auto On 31.400 4 low
gi1/0/5 Auto On 31.500 4 low
gi1/0/6 Auto On 31.0 4 low
gi1/0/7 Auto On 31.600 4 low
gi1/0/8 Auto Fault 0.0 0 low
Show the power supply status of the chosen interface:
console# showpowerinlinegi1/0/1
Interface Admin Oper Power (W) Class Device Priority
---------- ---------- ----------- ----------------- ----- -------------- --------
gi1/0/1 Auto Searching 0.0 0 low
Port Status: Port is off. Detection is in process
Port standard: 802.3AT
Admin power limit (for port power-limit mode): 30.0 watts
Time range:
Operational power limit: 30.0 watts
Spare pair: Disabled
Negotiated power: 0 watts (None)
Current (mA): 0
Voltage(V): 0.0
Overload Counter: 0
Short Counter: 0
Denied Counter: 0
Absent Counter: 0
InvalidSignatureCounter: 0
Description of the displayed power supply parameters is shown in the Table 5.162– Parameters of the
power supply status.
Table 5.162– Parameters of the power supply status
