ELTEX MES53xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 198
vrrp vrid version {2 | 3 |
2&3}
-/3
Specify supported version of VRRP.
- 2 - support for VRRPv2 defined in RFC3768. Received VRRPv3
messages are rejected by the router. Only VRRPv2
announcements are sent.
- 3 - support for VRRPv3 defined in RFC5798, without
compatibility with VRRPv2 (8.4, RFC5798). Received VRRPv2
messages are rejected by the router. Only VRRPv3 announces
are sent.
- 2&3 - support for VRRPv3 defined in RFC5798, with backward
compatibility with VRRPv2. Received VRRPv2 messages are
processed by the router. VRRPv2 and VRRPv3 announce are
sent.
Only VRRP version 3 is supported. Modes 2 and 2 and 3 will be
supported in future versions of the firmware.
no vrrp vrid version
Set the default value.
Privileged EXEC mode commands
All commands are available for privileged users only.
Command line prompt in the Privileged EXEC mode is as follows:
console#
Table 5.234. Privileged EXEC mode commands
Command
Value/Default value
Action
show vrrp [all | brief |
interface
{gigabitethernet gi_port |
tengigabitethernet te_port |
fortygigabitethernet fo_port |
port-channel group |
vlan vlan_id}]
gi_port: (1..8/0/1..48);
te_port: (1..8/0/1..24);
fo_port: (1..8/0/1..4);
group: (1..16);
vlan_id: (1..4094)
Show brief or detailed information for all or one configured
virtual VRRP router.
- all - show information about all virtual routers including
disabled ones;
- brief - show brief information about all virtual routers.
Examples of command usage
 Set IP address 10.10.10.1 to VLAN 10, use this address as address of virtual protocol of the router.
Enable VRRP on the VLAN interface.
console(config-vlan)# interface vlan 10
console(config-if)# ip address 10.10.10.1 /24
console(config-if)# vrrp 1 ip 10.10.10.1
console(config-if)# no vrrp 1 shutdown
 Show VRRP configuration:
console# show vrrp
Interface: vlan 10
Virtual Router 1
Virtual Router name
Supported version VRRPv3
State is Initializing
Virtual IP addresses are 10.10.10.1(down)
Source IP address is 0.0.0.0(default)
Virtual MAC address is 00:00:5e:00:01:01
Advertisement interval is 1.000 sec
Preemption enabled
Priority is 255
