MES53xx, MES33xx, MES23xx Ethernet Switch Series 205
Configuration example of the port in the customer mode
This type of connection can be used to mark users’ IGMP reports of specific VLANs (CVLANs) with
specific outer stamps (SVLAN).
1. Enable filtering of multicast data:
console(config)#bridge multicast filtering
2. Configure user VLANs (VID 100), multicast-tv VLAN (VID 1000, 1001), control VLAN (VID 1200):
console(config)#vlan database
console(config-vlan)#vlan 100,1000-1001,1200
console(config-vlan)#exit
3. Configure a user port:
console(config)#interface te1/0/1
console(config-if)#switchport mode customer
console(config-if)#switchport customer vlan 100
console(config-if)#switchport customer multicast-tv vlan add 1000,1001
console(config-if)#exit
4. Configure an uplink port by allowing transfer of multicast traffic, user traffic and control:
console(config)# interface te1/0/10
console(config-if)# switchport mode trunk
console(config-if)# switchport trunk allowed vlan add 100,1000-1001,1200
console(config-if)#exit
5. Configure IGMP snooping globally and on interfaces, add marking rules for user IGMP reports:
console(config)# ip igmp snooping
console(config)# ip igmp snooping vlan 100
console(config)# ip igmp snooping map cpe vlan 5 multicast-tv vlan 1000
console(config)# ip igmp snooping map cpe vlan 6 multicast-tv vlan 1001
6. Configure a control interface:
console(config)# interface vlan 1200
console(config-if)# ip address 192.168.33.100 255.255.255.0
console(config-if)# exit
