MES53xx, MES33xx, MES23xx Ethernet Switch Series 29

Figure 21. Device rack installation

Figure 22 shows an example of MES5324 rack installation.

Figure 22. MES5324 switch rack location

Do not block air vents and fans located on the rear panel to avoid components overheating

and subsequent switch malfunction.
