MES53xx, MES33xx, MES23xx Ethernet Switch Series 98
LLDP state: Enabled
Timer: 30 Seconds
Hold multiplier: 4
Reinit delay: 4 Seconds
Tx delay: 2 Seconds
Notifications Interval: 5 Seconds
LLDP packets handling: Filtering
Chassis ID: mac-address
Port State Optional TLVs Address Notifications
--------- ----------- -------------------- ----------------- ---------------
te1/0/7 Rx and Tx SN, SC None Disabled
te1/0/8 Rx and Tx SN, SC None Disabled
te1/0/9 Rx and Tx SN, SC None Disabled
te1/0/10 Rx and Tx PD, SD 10.10.10.70 Disabled
Table 5.86. Result description
Field
Description
Timer
Specify how frequently the device will send LLDP updates.
Hold multiplier
Specify the amount of time (TTL, Time-To-Live) for the receiver to keep LLDP packets
before dropping them: TTL = Timer * Hold multiplier.
Reinit delay
Specify the minimum amount of time for the port to wait before sending the next
LLDP message.
Tx delay
Specify the delay between the subsequent LLDP frame transmissions initiated by
changes of values or status.
Port
Port number.
State
Port operation mode for LLDP.
Optional TLVs
TLV options
Possible values:
PD Port description;
SN System name;
SD System description;
SC System capablities.
Address
Device address sent in LLDP messages.
Notifications
Specify whether LLDP notifications are enabled or disabled.
Show information on neighbour devices:
console# show lldp neighbors
Port Device ID Port ID System Name Capabilities
--------- ---------------- -------- ---------- -------------
te0/1 0060.704C.73FE 1 ts-7800-2 B
te0/2 0060.704C.73FD 1 ts-7800-2 B
te0/3 0060.704C.73FC 9 ts-7900-1 B, R
te0/4 0060.704C.73FB 1 ts-7900-2 W
console# show lldp neighbors tengigabitethernet 1/0/20
