Light indication of Ethernet 1000/100 interfaces
Ethernet interfaces state is shown by LED indicators built into 1000/100 connectors. Possible states are listed
in the Table below.
Table 11 — Light indication of Ethernet 1000/100 interfaces
Device Status
LED/Status
Yellow LED 1000/100
Green LED 1000/100
A port runs in 1000BASE-T mode, no data transfer
always on
always on
A port runs in 1000BASE-T mode, data transfer available
always on
flashes
A port runs in 10/100BASE-TX mode, no data transfer
off
always on
A port runs in 10/100BASE-TX mode, data transfer available
off
flashes
Light indication during device boot and reset to factory defaults
2.5.3.1 SBC-1000
For light indication during device boot and reset to factory defaults, see Table 12.
Table 12 — Light indication during device boot and reset to factory defaults
№
Indication
Reset to factory defaults procedure
(device in operation)
Info1
Info1
Alarm
Status
1
yellow
yellow
yellow
yellow
Press and hold the F button for 1 second until the
following pattern appears. The device will be rebooted
in 3 seconds
2
green
red
yellow
red
Reset to factory defaults has been initiated. This LED
pattern will appear only when the device boot begins
3
yellow
yellow
yellow
yellow
At this step, LED functionality check will be performed:
all LEDs including SATA-0 and SATA-1 will light up
yellow.
4
off
off
green
green
At this step, the gateway operating system boot will be
performed. To change network parameters and to reset
the device configuration to factory defaults, press and
hold the F button for 40-45 seconds when the pattern
appears (when you hold the button, pattern 2 may
appear shortly; ignore it and continue holding the
button until the pattern 4 appears).
5
yellow
yellow
yellow
yellow
When the pattern appears, release the F button.
After a while, the following message will be displayed in
the console.
<<<BOOTING IN SAFE-MODE.RESTORING DEFAULT
PARAMETERS>>>
Reset to the factory settings complete
It is not recommended to hold down the "F" button while resetting the device: this will bring it to a
complete stop. Resumption of operation will only be possible after a power reset.
It is also possible to reset to factory settings on the device being switched on.
In this case, skip the 1st step.
