Flow Measurement System Version 1.00 page 23 of 75
6.2.2.1 Pin Assignment and Cable Colors for Round Connector for Digital
Interface
Please note: the supplied cable for the digital interface is completely wired and ready to
use.
Wire color
(in supplied cabling)
6.2.2.2 Pin Assignment and Cable Colors for Round Connector for Power
Analogue Flow and RSS Interfaces
Please see chapter BASIC CONSIDERATIONS AND POWERING OF FLOW METER
AND 4-20 MA CIRCUITS for details.
Sourcing information for plugs:
The 768/718 series from Binder is used for the connections of the BioProTT™ flow meter.
The circular plug design optimally supports the flow measurement application.
Please note: unused connector sockets should be covered with the provided flexible grip
caps. For additional protection the use of suitable screw caps for all sockets that are not
connected/in use is recommended.
