Flow Measurement System Version 1.00 page 64 of 75
Tubing; Raumedic-ECC-Blood Line Tubing
Other tubing materials on request
Medium operating temperature
4 to 50 ºC (40 to 122°F)
Supported flow meters
BioProTT™ FlowTrack, Bio ProTT™ FlowTrack
plus, BioProTT™ FlowTrack DINrail
Repeatability
* Reference conditions
Liquid temperature
Ambient temperature
Straight inlet section
Tubing
Dependent on tubing size, wall thickness and
material and manufacturing tolerances
Calibration temperature ±5K
20°C ±5K
10x ID of tubing, fully developed flow profile
Raumedic-ECC-Blood Line PVC
Please note: as the measurement allows a maximal flexibility with respect to
positioning the sensor the given accuracy is a standard under the reference conditions.
Certain setups allow higher levels of accuracy and can be evaluated by a factory
calibration certificate on customer request.
Ambient conditions:
Air pressure
70 to 106 kPa
Operating altitude
up to max. 2000 m
Operating temperature range
4ºC to 50ºC (40°F to 122°F)
Storage temperature range
–20°C to 45°C (-4°F to 113°F)
Transport temperature range
–20°C to 55°C (-4°F to 131°F)
Relative air humidity:
Operation
30% to 75% (non-condensing)
Storage and transportation
10% to 96% (non-condensing)
Customer-specific calibrations for different flow mediums, tubing materials e.g. Silicone,
PVC, Masterflex tubing and medium temperatures can be made upon request.
Each sensor can store up to 7 different calibration tables in the sensor plug.
BioProTT™ Clamp-On Transducer Sizes* and Flow Measurement Range
Type
Maximum
Flow Range**
Tube size in inch
Tube size in mm
[l/min]
ID x WT [“]
OD [“]
ID x WT [mm]
OD [mm]
BCT 1/8 x 1/16” A
up to ± 4
1/8 x 1/16
1/4
3.18 x 1.59
6.35
BCT 11/64 x 3/64” A
up to ± 6
11/64 x 3/64
17/64
4.30 x 1.25
6.80
BCT 3/16 x 1/16”A
up to ± 6
3/16 x 1/16
5/16
4.76 x 1.59
7.94
BCT 1/4 x 1/16” A
up to ± 8
1/4 x 1/16
3/8
6.35 x 1.59
9.53
BCT 1/4 x 3/32” A
up to ± 8
1/4 x 3/32
7/16
6.35 x 2.38
11.11
BCT 3/8 x 1/16” A
up to ± 10
3/8 x 1/16
1/2
9.53 x 1.59
12.70
