EM TEST Compact NX5
Operating Manual V 1.06 123 / 143
12.9.2.3.
Technical data Motorvariac variac NX-1-260-16
Input:
Voltage Vin: max. 250 V
Frequency 50/60 Hz
Output
Voltage variable Vout: 0 260 V for channel PF2
Voltage fix Vout: Vin for channel PF1
Current max: 16 A
Power 0 - 4.1 kVA
Control
Main switch On/Off for the output voltages
Control voltage analogue 0 - 10V DC for 0-260V output voltage
Time 0..100% < 2s
Dimensions and weight
Dimensions 19" 6HE 266x485x400mm (H x W x D)
Weight app 27 kg
Power supply 115/230 V
Fuse 20 A (PF1), 16 A (PF2)
Environment Tmax 40C
