EM TEST compact NX5 Series User Manual

EM TEST Compact NX5
Operating Manual V 1.06 73 / 143
6.5.
EUT Supply Specifications
Standard models
Model
CDN
Remarks
compact NX5
300V 16A 1- phase
DC 300 V / 16 A
EUT Fuse
The compact NX5 models have no internal fuse for the EUT supply.
The user is responsible to adapt a suitable fuse for the EUT outside the compact NX5
6.6.
General Specifications
Mains supply
85 to 264 Vac, 50/60Hz
Power consumption
75 W
Fuse
2 x 2 AT slow blow
Safety
Safety circuit
External interlock capability
Warning lamp
voltage free contact max. 60 V 2 A
Design
As per IEC 1010, EN 61010
Interfaces
Serial interface
1 x USB A front side for memory stick
1 x USB A rear side
1 x USB B
1x opto-link
LAN
Ethernet
SYS link IN, OUT
26 pin high density Sub D to control external devices
Analog output
0-10V DC, to control an external power supply
EUT1, EUT 2 input
Digital input
+ 15 V to 0 V, negative slope to zero
Trigger level
2 V ±1 V
Input impedance
> 10 kΩ
Max. Input voltage
+ 15 V
compact NX5
Dimensions
19" / 3 HU
Weight
app. 25 kg
6.7.
Environmental conditions
Temperature
10 °C to 35 °C
Humidity
30 % to 70 %; non condensing
Atmospheric pressure
86 kPa (860 mbar) to 106 kPa (1 060 mbar)
=> Not relevant data for the standards can be changed by the manufacturer <=
