EM TEST Compact NX5
Operating Manual V 1.06 94 / 143
User Test Routines
The user can program, save and recall his own specific test routines. The next pages show the selection of the
functions.
The extended menu offers various useful tests for testing and development.
Change test level V after n pulses by V
The test voltage V is changed from V1 to V2. After the preselected
number pulses the test level is changed by V until V2 is reached.
The same parameters as under Quick Start are selectable.
For the limitation of the max. admissible repetition rate the
higher value of V1 and V2 is valid.
Angle Iteration Stepwise after n pulses by A
The phase angle related to which the surge pulse is
released is changed from A1 to A2. After the preselected
number of n pulses the actual phase angle is changed by A
until A2 is reached. The same parameters as under Quick
Start can be selected.
Angle Random Iteration
The phase iterated angle will be played in random mode.
After the test all steps are tested once.
