EM TEST compact NX5 Series User Manual

EM TEST Compact NX5
Operating Manual V 1.06 77 / 143
Surge
Power Fail
 V4780 transformer with taps
- Transformer with taps at 40%&, 70%, 80%
- 230V / 16A
 Variac NX-1-260-16
- Motorvariac 0-260 V / 16 A or 32 A
- Control signal 0-10 Vdc.
Magnetic field
MS 100N Magnetic field antenna
 MC 2630 Current transformer up to 30 A/m
 MC 26100 Current transformer up to 1000 A/m
MC 2630 MC 26100
General for Burst and Surge
 Coupling NX5 bs-3-480-16 external coupling/decoupling network
- EUT mains supply 480 V rms max
- Nominal current In = 16 A / 32A / 63A / 100 A rms
- Frequency 50/60 Hz
- Coupling to all lines, N, PE
- 50 Burst output The coupling will be controlled by the compact NX5
- Output for Surge coupling to other coupling networks as CNV models.
 User software " iec.control "
- Test, analysis and documentation with Windows
- License version for testing according the most automotive standards
- Report generator with export function to word-processing software
UOC optical Interface
 USB-Optolink Converter
- USB Optolink converter
- Optical Fibre cable, 5m

EM TEST compact NX5 Series Specifications

General

Brand	EM TEST
Model	compact NX5 Series
Category	Laboratory Equipment
Language	English
