EM Test CWS500 D
User manual V 1.07 10 / 34
4.2. Quickstart
Easy and very fast operation for functions check and verification of the CWS 500D.
Page 2 (Show Parameters) Page 3 (Change)
Quickstart Quickstart
Att = 63,0 dB f = 109.500 MHz
Mod = AM 1kHz 80% Att : 0.0 dB - 63.5 dB
f : 0.009 MHz - 400.0 MHz
Mod : OFF, AM 80%, AM 90%, Pulse
Att f Mod
START CHANGE 57.0 109.5 ON
F1 F2 F3 F4 F5 F6 F7 F1 F2 F3 F4 F5 F6 F7
Press START to begin testing.
Press CHANGE and the actual parameters can be changed. Selecting a parameter to change will display the
range.
The test begins by pressing START. The blinking parameter can be changed with the knob inc./dec.
Use the cursor keys (ÍÎ ) to select other parameters. By pressing STOP the test will be stopped and on the
last line of the display it will be indicated that the test has been stopped.
Page 3 (Operating)
Quickstart
Att = 33,0 dB f = 109.500 MHz
Mod = AM 1kHz 80%
FPow = - 9.7 dBm Mon = -56.9 dBm
Rpow = - 16.5 dBm
STOP
F1 F2 F3 F4 F5 F6 F7
Error messages:
Quickstart
Att = 40,0 dB f = 109.500 MHz
Mod = off
FPow = + 6.6 dBm Mon = -57.3 dBm
Rpow = + 6.8 dBm
Fpow to low !
Message : Fpow to low !
What happens : The amplifier does not supply the expected gain. The firmware checks the ratio between the
signal generator output and the Forward power. The reason can be an amplifier defect or an
internal error in the CWS 500D. This message appears only when using internal amplifier.
