User manual V 1.07 12 / 34
4.3. Display during Remote control
The CWS 500 can only work with remote control from the ICD software Version 3.00 or higher. During the
operation the following information appears on the display:
Remote control
R E M O T E ProgRemote
f = 5.420MHz Mod = OFF
FPow = -17.6 dBm
FPow = ----- dBm
Mon = -30.4 dBm Dwell Time 0.3s
During Remote operation the display shows different screens depend the actual software procedure
Waiting
R E M O T E AMP : 1
f = 10.538 MHz AM = off
td = 0.3 s PM1 = off
PM 2 = off
Display during a test
