EM Test CWS500 D
User manual V 1.07 15 / 34
4.4.2. Setup
This menu helps the user to define the configuration of the CWS 500D.
Page 3 (Setup Overview)
Setup
F1 : Change language / Sprache ändern
F2 : LCD Back Lighting
F3 : Interfaces
F4 : Keyboard Beeper
F5 : Timer
F1 F2 F3 F4 F5 F6 F7
F1 Change language / Sprache ändern
The user can choose between two languages, German and English.
F2 LCD Back Lighting
With the use of F2 the back lighting can be switched ON or OFF. The Auto-Off Function can be programmed to
switch the back lighting off after a predetermined time following the last manual operation (1 - 30 minutes).
Due to the limited lifetime of the LCD back lighting (approx. 10,000 hours), this function should always be
activated.
The Auto ON/OFF function does not switch on during remote operating
F3 Interfaces
With this menu the user can define the status of the integrated serial and parallel interfaces, e.g. the baud rate
of the RS232- or the address of the IEEE-interface.
F4 Keyboard Beeper
F4 selects the beeper ON/OFF mode.
F5 Timer
By pressing F5 will display the total operating time of the CWS 500D will be displayed.
4.4.3. Amplifier Switch
Change of the used amplifier internal or external
Page 3 (Amplifier Switch)
Amplifier Switch
F1 : Amplifier Int / Ext
Int / Ext
Int
F1 F2 F3 F4 F5 F6 F7
The CWS display shows the actual setting for the used amplifier
Int : Internal = Amp 1
Ext : External = Amp 2
After power on the default amplifier is set to internal
