EM TEST CWS 500D - Safety Aspects; Connections CWS 500 D; Test Setup CWS 500 D

EM Test CWS500 D
User manual V 1.07 3 / 34
1. Safety Aspects
+
Before using the CWS 500 D read the following manuals carefully :
- Safety requirements manual
- Manual for operation CWS 500D
2. Setup the CWS 500D
2.1. Connections CWS 500D
Below are all possible connections to the CWS 500D
400MHz model figure 2.1
1000MHz model figure 2.2
Fig 2.1 : CWS 500D (400MHz) connection rear view Fig 2.2 : CWS 500D ( 1 GHz) connection rear view
2.2. Test Setup CWS 500D
Figure 2.3a / 2.3b :
Typical test setup with
required parts for BCI
application with CWS
500D
