Installation
Page 34
● An AC power port should be available near to the pilot plug. A pilot plug is located on the front panel
of the AIS transceiver and can also be relocated using the junction box. Please refer to section
4.4.2
for guidance.
Figure 34 AIS transceiver dimensions
Figure 35 Mounting the AIS transceiver
105 mm
85 mm
195 mm
172 mm
112 mm
157 mm
