Em-Trak A100 - TDMA Receivers; DSC Receiver; RF Connections

Technical Specifications
Page 57
5.9 TDMA receivers
5.10 DSC receiver
5.11 RF connections
Number of receivers 2
Frequency range 156.025MHz to 162.025MHz
Channel bandwidth 25kHz
Sensitivity <-107dBm for 20% PER
Modulation mode 25kHz GMSK
Adjacent channel selectivity 70dB
Spurious response rejection 70dB
Number of receivers 1
Frequency 156.525MHz (Channel 70)
Channel bandwidth 25kHz
Sensitivity -107dBm @ BER <10
-2
Modulation mode 25kHz AFSK
Adjacent channel selectivity 70dB
Spurious response rejection 70dB
VHF antenna connection SO-239 / UHF
VHF port impedance 50 Ohms
GNSS antenna connection TNC female
GNSS port impedance 50 Ohms
