Installation
Page 42
Table 4 Serial data port connections
*This setting relates to IEC61162-1 or IEC61162-2 operation.
Data port
Junction box signal
label
Description Function
Sensor 1 SEN1 A Sensor port 1 input A Connect to data source, typically
ships primary GNSS at 4800baud.
This port can be configured to
operate at either 4800 or 38400
baud*.
SEN1 B Sensor port 1 input B
SEN1 GND Sensor port 1 isolated ground
Sensor 2 SEN2 A Sensor port 2 input A Connect to data source, typically
gyro or heading. This port can be
configured to operate at either
4800 or 38400 baud*.
SEN2 B Sensor port 2 input B
SEN2 GND Sensor port 2 isolated ground
Sensor 3 SEN3 A Sensor port 3 input A Connect to data source, typically
ROT or speed. This port can be
configured to operate at either
4800 or 38400 baud*.
SEN3 B Sensor port 3 input B
SEN3 GND Sensor port 3 isolated ground
External
display
EXT_DISP_IN A External display input A Connect to the data output of an
external display system, typically
an ECDIS. This port operates at
38400 baud.
EXT_DISP_IN B External display input B
EXT_DISP_IN GND External display input ground
(isolated)
EXT_DISP_OUT A External display output A Connect to the data input of an
external display system, typically
an ECDIS. This port operates at
38400 baud.
EXT_DISP_OUT B External display output B
EXT_DISP_OUT GND External display output
ground
Pilot PILOT_IN A External display input A Connections for the pilot port.
These connections duplicate the
pilot plug on the front panel of the
transceiver and can be used to
relocate the pilot plug if required.
If relocating the pilot plug note
that AMP/Receptacle (Square
Flanged (-1) or Free-Hanging
(-2)), Shell size 11, 9-pin, Std. Sex
206486-1/2 or equivalent with the
following terminations must be
used.
- TX A is connected to Pin 1
- TX B is connected to Pin 4
- RX A is connected to Pin 5
- RX B is connected to Pin 6
- Shield is connected to Pin 9
PILOT_IN B External display input B
PILOT_IN GND External display input ground
(isolated)
PILOT_OUT A External display output A
PILOT_OUT B External display output B
PILOT_OUT GND External display output
ground
