Celerra Network Server Command Reference Manual
The nas Commands
18 y 34687 000187940260-002F STD d18 1,2,3,4,5,6,7,8
19 y 34687 000187940260-0038 STD d19 1,2,3,4,5,6,7,8
20 y 34687 000187940260-0039 STD d20 1,2,3,4,5,6,7,8
21 y 34687 000187940260-003A STD d21 1,2,3,4,5,6,7,8
22 y 34687 000187940260-003B STD d22 1,2,3,4,5,6,7,8
23 y 34687 000187940260-003C STD d23 1,2,3,4,5,6,7,8
24 y 34687 000187940260-003D STD d24 1,2,3,4,5,6,7,8
Where:
EXAMPLE #2 For the Celerra Network Server with a CLARiiON backend, to view
information for a specific disk such as size, type and ACL, type:
$ nas_disk -info d7
id = 7
name = d7
acl = 0
in_use = True
size (MB) = 273709
type = CLSTD
protection= RAID5(4+1)
stor_id = APM00042000818
stor_dev = 0012
volume_name = d7
storage_profiles = clar_r5_performance
mirrored = False
servers = server_2,server_3,server_4,server_5
server = server_2 addr=c0t1l2
server = server_2 addr=c32t1l2
server = server_2 addr=c16t1l2
server = server_2 addr=c48t1l2
server = server_3 addr=c0t1l2
server = server_3 addr=c32t1l2
server = server_3 addr=c16t1l2
server = server_3 addr=c48t1l2
server = server_4 addr=c0t1l2
server = server_4 addr=c32t1l2
server = server_4 addr=c16t1l2
server = server_4 addr=c48t1l2
server = server_5 addr=c0t1l2
server = server_5 addr=c32t1l2
server = server_5 addr=c16t1l2
Value Indicates the:
id ID of the disk (assigned automatically).
inuse used by any type of volume or file system.
sizeMB total size of disk.
storageID-devID ID of the storage system and device associated with the disk.
type type of disk contingent on the backend attached. CLSTD, CLATA, CMSTD and CMATA are for CLARiiON,
and STD, BCV, R1BCV, R2BCV, R1STD, R2STD, ATA, R1ATA, R2ATA,BCVA, R1BCA, R2BCA are for
Symmetrix.
name name of the disk. Two d’s (dd) in a disk name indicate a remote disk.
servers servers that have access to this disk.
