Note
The calculation for loop resistance must include 100 ohms for the mA Input.
Postrequisites
To configure your system for SIS applications, see the Coriolis Flow Meter with Micro Motion
5700 Transmitters Safety Manual for Safety Instrumented Systems (SIS) and the Micro Motion
5700 Transmitters with Configurable Inputs and Outputs: Configuration and Use Manual.
Installation Manual Wiring the channels
MMI-20027478 April 2022
Installation Manual 43
