PACSystems Ethernet Switch SLM042 User Manual Section 3
GFK-3123A Jan 2020
Hardware Overview 6
3.3 Front Panel LEDs
LED
Color
Status
Description
PWR1
Green
On
DC power module 1
activated.
PWR2
Green
On
DC power module 2
activated.
PWR3
Green
On
Power jack activated.
R.M
Green
On
Ring Master.
Ring
Green
On
Ring enabled.
Slowly
blinking
Ring topology has problem
Fast blinking
Ring work normally.
Fault
Amber
On
Fault relay. Power failure or
Port down/fail.
10/100Base-T(X) Fast Ethernet ports
LNK / ACT
Green
On
Port link up.
Blinking
Data transmitted.
LINK
Amber
On
LINK Led
100Base-FX Fiber ports
ACT
Green
Blinking
Data transmitted.
LNK
Amber
On
Link Led
