Section 3: Hardware Overview
3.1 Front Panel
The following table describes the labels that stick on the SLM042.
Port
Description
10/100 RJ-45 fast
Ethernet ports
10/100Base-T(X) RJ-45 fast Ethernet ports support auto-
negotiation.
Default Setting :
Speed: auto
Duplex: auto
Flow control : disable
Fiber port
100Base-FX for SLM042series switches
Reset
Push reset button 2 to 3 seconds to reset the switch.
Push reset button 5 second to reset the switch into
Factory Default.
