5.6.5 Fault Relay Alarm
When any selected fault event is happened, the Fault LED in switch panel will light up and the
electric relay will signal at the same time.
Figure 28: Fault Relay Alarm
5.7 Save Configuration
If any configuration changed, “Save Configuration” should be clicked to save current
configuration data into the permanent flash memory. Otherwise, the current configuration
will be lost when power off or system reset.
Figure 29: Save Configuration
The following table describes the labels in this screen.
