Emerson Rosemount 702 - 8.9.2 IY IECEx Intrinsic Safety for Zone 2

Sensor terminal
parameters (option code
32)
Fuel sensor terminal
parameters (option code
61)
Plunger arrival
transmitter parameters
(option code 52)
U
O
= 6.51 V U
O
= 7.8 V U
O
= 6.6 V
I
O
= 13.37 mA I
O
= 92 mA I
O
= 125 mA
P
O
= 21.76 mW P
O
= 180 mW P
O
= 202 mW
C
i
= 0.216 µF C
i
= 10 nF C
i
= 8.36nF
C
O IIC
= 21.78 µF C
O IIC
= 9.2 µF Li = 0
C
O IIB
= 549.78 µF C
O IIB
= 129 µF C
O
= 74 nF
C
O IIA
= 1000 µF C
O IIA
= 1000 µF L
O
= 1.5 mH
L
i
= 0 L
i
= 0 N/A
L
O IIC
= 200 mH L
O IIC
= 4.2 mH N/A
L
O IIB
= 800 mH L
O IIB
= 16.8 mH N/A
L
O IIA
= 1000 mH L
O IIA
= 33.6 mH N/A
Special Conditions for Safe Use (X):
1. The surface resistivity of the antenna is greater than 1 GΩ. To avoid
electrostatic charge build-up, it must not be rubbed or cleaned with
solvents or dry cloth.
2. The Model 701PBKKF Power Module, MHM-89004 Blue Power
Module, or Intelligent Power Module 71008 may be replaced in a
hazardous area. The Power Modules have a surface resistivity greater
than 1 GΩ and must be properly installed in the wireless device
enclosure. Care must be taken during transportation to and from the
point of installation to prevent electrostatic charge build-up.
3. The Rosemount 702 enclosure may be made of aluminum alloy and
given a protective polyurethane paint finish; however, care should be
taken to protect it from impact or abrasion if located in a Zone 0
area.
8.9.2 IY IECEx Intrinsic Safety for Zone 2
Certificate:
IECEx BAS 12.0082X
Standards:
IEC 60079-0: 2017, IEC 60079-11: 2011
Markings:
Ex ic IIC T4 Gc (-60 °C ≤ T
a
≤ 70 °C)
Ex ic IIC T5 Gc (-60 °C ≤ T
a
≤ 40 °C)
