ZX Platform Condensing Unit
42
5.Only ZXL TF5 has 4 additional posts on
the terminal block.
ZX/ZXL Condensing Unit Wiring Diagram
TFD: 380V/420V -50 Hz-3Ph
TF7: 380V-60 Hz -3Ph
ATTENTION: Unit MUST be grounded!
