EMS DOLORCLAST User Manual

20
5. PRESET PROTOCOLS
5.1. DESCRIPTION OF PRESET PROTOCOLS
You can use preset protocols as a starting point instead of adjusting each setting manually. Preset protocols are
available to help you target treatment and increase efciency.
Preset protocols are classied into six families:
PRESET PROTOCOLS FACTORY SETTINGS
SMART Protocol (Default) 2 bar / 15 Hz / 2500 impulses
Tendinopathy 1.5 bar / 15 Hz / 3000 impulses
Enthesopathy 1 bar / 15 Hz / 3000 impulses
Joint & Bone 2 bar / 15 Hz / 3000 impulses
Skin 2.5 bar / 20 Hz / 3000 impulses
Recovery 2.5 bar / 25 Hz / 4000 impulses
Muscle 2 bar / 25 Hz / 4000 impulses
Table 2
5.2. SELECTING THE PRESET PROTOCOLS
1. To select a preset protocol, use the and
buttons. The name of the preset protocol is shown on
the display along with the associated factory settings.
Figure 38
2. Press the trigger on the handpiece to start treatment.
5.3. ADJUSTING THE PRESET PROTOCOLS
You can modify a preset protocol to adapt the
treatment.
1. To adjust the settings of a given preset protocol
according to the patient’s treatment, rst select the
preset protocol.
2. Use the and buttons to adjust the settings.
For more information about how to adjust the set-
tings, refer to the “Treatment Settings” section.
3. The new settings are displayed and an asterisk *
appears after the protocol’s name to specify that this
preset protocol has been customized.
bar
Hz
Impulses
2.5
15
2500
ENTHESOPATHY*
Figure 39
bar
Hz
Impulses
1.0
15
3000
ENTHESOPATHY
