28
e. Pull on the piston to remove it from the handpiece.
Figure 59
3. Discard the worn piston according to the regulations
that apply in your country.
Figure 60
4. Unpack the new piston and make sure to remove
the piston cap before installing the new piston on the
handpiece.
Figure 61
5. Install the new piston on the handpiece.
6. Re-assemble the handpiece.
8.1.2. Applicator O-ring
EMS recommends to change the o’rings when
the piston is changed
8.1.2.1. For 5-mm, 10-mm and 15-mm Applicators
1. Disassemble the applicator.
Figure 62
2. If the O-ring is damaged or worn, it must be replaced
immediately.
Figure 63
3. Use the O-ring maintenance kit and select the relevant
O-ring according to the applicator size.
00_FB-656_10_rev_A_IFU_Dolorclast RSW.indb 2800_FB-656_10_rev_A_IFU_Dolorclast RSW.indb 28 25/03/2021 17:0725/03/2021 17:07
