EMS DOLORCLAST User Manual

34
Guidance and Manufacturer’s Declaration – Electromagnetic Emissions
The DOLORCLAST
®
Radial Shock Waves is intended for use in the electromagnetic environment specied below.
The customer or the user of the DOLORCLAST
®
Radial Shock Waves should assure that it is used in such an
environment.
EMISSIONS TEST COMPLIANCE ELECTROMAGNETIC ENVIRONMENT – GUIDANCE
RF emissions
CISPR 11
Group 1 The DOLORCLAST
®
Radial Shock Waves uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not likely to cause
any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B The DOLORCLAST
®
Radial Shock Waves is suitable for use in all establish-
ments, including domestic establishments and those directly connected to
the public low-voltage power supply network that supplies buildings used for
domestic purposes.
Harmonics emissions
IEC 61000-3-2
Class B
Voltage uctuations / icker
emissions IEC 61000-3-3
Complies
Table 3
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The DOLORCLAST
®
Radial Shock Waves is intended for use in the electromagnetic environment specied
below. The customer or the user of DOLORCLAST
®
Radial Shock Waves should ensure that it is used in such an
environment.
IMMUNITY TEST
IEC 60601
TEST LEVEL
COMPLIANCE LEVEL
ELECTROMAGNETIC ENVIRONMENT -
GUIDANCE
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 8 kV contact
± 2, ± 4, ± 8, ± 15 kV air
± 8 kV contact
± 2, ± 4, ± 8, ± 15 kV air
Floors should be wood, concrete or ceramic tile.
If oors are covered with synthetic material, the
relative humidity should be at least 30 %.
Electrical fast
transient / burst
IEC 61000-4-4
± 2 kV, 100 kHz
for power supply lines*
± 1 kV, 100 kHz
for input/output lines*
± 2 kV, 100 kHz
for power supply lines*
± 1 kV, 100 kHz
for input/output lines*
Mains power quality should be that of typical
commercial or hospital environment.
*Not applicable for DC and I/O if cable < 3 m
Surge
IEC 61000-4-5
±0.5, ±1 kV
line(s) to line(s)*
±0.5, ±1, ± 2 kV
line(s) to earth*
±0.5, ±1 kV
line(s) to line(s)*
±0.5, ±1, ± 2 kV
line(s) to earth*
Mains power quality should be that of typical
commercial or hospital environment.
*Not applicable for DC and I/O if cable < 3 m
Power frequency
(50/60 Hz)
magnetic eld
IEC 61000-4-8
30 A/m 30 A/m
Power frequency magnetic elds should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
Voltage dips,
short interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
0 % UT: 0.5 cycle
At 0°, 45°, 90°, 135°,
180°, 225°, 270° and
315°
0 % UT: 1 cycle
At 0°
0 % UT: 250/300 cycles
At 0°
70 % UT: 25/30 cycles
At 0°
0 % UT: 0.5 cycle
At 0°, 45°, 90°, 135°,
180°, 225°, 270° and
315°
0 % UT: 1 cycle
At 0°
0 % UT: 250/300 cycles
At 0°
70 % UT: 25/30 cycles
At 0°
Mains power quality should be that of a typical
commercial or hospital environment. If the user
of the DOLORCLAST
®
Radial Shock Waves
requires continued operation during power
mains interruptions, it is recommended that the
SWISS DOLORCLAST
®
Radial Shock Waves be
powered from an uninterruptible power supply or
a battery.
*Not applicable for DC and I/O if cable < 3 m
UT is the AC mains voltage (100-240) prior to
application of the test level.
Table 4
00_FB-656_10_rev_A_IFU_Dolorclast RSW.indb 3400_FB-656_10_rev_A_IFU_Dolorclast RSW.indb 34 25/03/2021 17:0725/03/2021 17:07
