Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The DOLORCLAST
®
Radial Shock Waves is intended for use in the electromagnetic environment specied below.
The customer or the user of the DOLORCLAST
®
Radial Shock Waves should ensure that it is used in such an
environment.
Portable and mobile RF communications equipment should be used no closer to any part of the DOLORCLAST
®
Radial Shock
Waves, including cables, than the recommended separation distance calculated from the equation applicable to the frequency
of the transmitter.
These guidelines may not apply to all situations. Electromagnetic propagation is affected by absorption and reection from struc-
tures, objects and people. Field strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones
and land mobile radios, amateur radios, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to xed RF transmitters, an electromagnetic site survey should be
considered.
IMMUNITY
TEST
IEC 60601
TEST LEVEL
COMPLIANCE
LEVEL
ELECTROMAGNETIC ENVIRONMENT – GUIDANCE
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
outside ISM bands
and radio amateur
band *
6 Vrms
150 kHz to 80 MHz
outside ISM bands
and radio amateur
band *
If the measured eld strength in the location in which the
DOLORCLAST
®
Radial Shock Waves is used exceeds the
applicable RF compliance level above, the SWISS DOLOR-
CLAST
®
Radial Shock Waves should be observed to verify
normal operation. If abnormal performance is observed,
additional measures may be necessary, such as re-orienting
or relocating the DOLORCLAST
®
Radial Shock Waves.
6 Vrms
150 kHz to 80 MHz
in ISM bands and
radio amateur
band*
6 Vrms
150 kHz to 80 MHz
in ISM bands and
radio amateur
band*
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.7 GHz
80 % AM at 1KHz
3 V/m
80 MHz to 2.7 GHz
80 % AM at 1KHz
Minimum separation distance shall be calculated by following
equation:
E =
6
P
d
E is the immunity test level in [V/m]
d is the minimum separation in [m]
P is the maximum power in [W]
Proximity
elds from
RF wireless
commu-
nication
equipment
IEC 61000-4-3
27 V/m
380-390 MHz
50 % PM 18 Hz
28 V/m
430-470 MHz
FM ±5 kHz
deviation,
1 kHz sine
9 V/m
704-787 MHz
50 % PM 217 Hz
28 V/m
800-960 MHz
50 % PM 18 Hz
28 V/m
1700-1990 MHz
50 % PM 217 Hz
28 V/m
2400-2570 MHz
50 % PM 217 Hz
9 V/m
5100-5800 MHz
50 % PM 217 Hz
27 V/m
380-390 MHz
50 % PM 18 Hz
28 V/m
430-470 MHz
FM ±5 kHz
deviation,
1 kHz sine
9 V/m
704-787 MHz
50 % PM 217 Hz
28 V/m
800-960 MHz
50 % PM 18 Hz
28 V/m
1700-1990 MHz
50 % PM 217 Hz
28 V/m
2400-2570 MHz
50 % PM 217 Hz
9 V/m
5100-5800 MHz
50 % PM 217 Hz
RF wireless equipment maximum output power and
separation distance tested (at 30 cm):
TETRA 400: max 1.8 W
GMRS 460, FRS 460: max 2 W
LTE Band 13, 17: max 0.2 W
GSM 800/900: max 2 W
TETRA 800: max 2 W
iDEN 820: max 2 W
CDMA 850: max 2 W
LTE Band 5: max 2 W
GSM 1800/1900: max 2 W
CDMA 1900: max 2W
DECT: max 2 W
LTE Band 1,3,4,25: max 2 W
UMTS: max 2 W
Bluetooth: max 2W
WLAN 802.11b/g/n: max 2 W
RFID 2450: max 2 W
LTE Band 7: max 2 W
WLAN 802.11 a/n: max 0.2 W
Interference may occur in the vicinity of equipment marked
with the following symbol:
*The ISM (industrial, scientic and medical) bands between 150 kHz and 80 MHz are 6.765 - 6.795 MHz, 13.553 - 13.567 MHz, 26.957 -
27.283 MHz and 40.66 - 40.7 MHz. The amateur radio bands between 0.15 MHz and 80 MHz are 1.8 MHz - 2 MHz, 3.5 - 4.0 MHz, 5.3 -
5.4 MHz, 7 - 7.3 MHz, 10.1 - 10.15 MHz, 14 - 14.2 MHz, 18.07 - 18.17 MHz, 21.0 - 21.4 MHz, 24.89 - 24.99 MHz, 28.0 - 29.7 MHz and 50.0 -
54.0 MHz.
If the measured eld strength in the location in which the DOLORCLAST
®
Radial Shock Waves is used exceeds the applicable RF compliance
level above, the DOLORCLAST
®
Radial Shock Waves should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as reorienting or relocating the DOLORCLAST
®
Radial Shock Waves
Table 5
