EMS DOLORCLAST User Manual

36
Recommended separation distances between portable and mobile RF communications
equipment and the DOLORCLAST
®
Radial Shock Waves
The DOLORCLAST
®
Radial Shock Waves is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The customer or the user of the DOLORCLAST
®
Radial Shock Waves
can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile
RF communications equipment (transmitters) and the DOLORCLAST
®
Radial Shock Waves as recommended
below, according to the maximum output power of the communications equipment.
Rated
maximum
output power
of transmitter
SEPARATION DISTANCE ACCORDING TO FREQUENCY OF TRANSMITTER [M]
150 kHz to 80 MHz outside
ISM and radio amateur bands*
d = 1.0√P
150 kHz to 80 MHz outside
ISM and radio amateur bands*
d = 1.0√P
80 MHz to 2700 MHz (for dene RF
Wireless transmitters see table before)
d = 0.60√P
0.01 W 0.1 0.1 0.06
0.1 W 0.32 0.32 0.19
1 W 1.0 1.0 0.60
10 W 3.2 3.2 1.9
100 W 10 10 6.0
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters [m] can
be determined using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of
the transmitter in watts [W] according to the transmitter manufacturer.
E =
6
P
d
*The ISM (industrial, scientic and medical) bands between 150 kHz and 80 MHz are 6.765 - 6.795 MHz, 13.553 - 13.567 MHz,
26.957 - 27.283 MHz and 40.66 - 40.7 MHz. The amateur radio bands between 0.15 MHz and 80 MHz are 1.8 MHz - 2 MHz, 3.5 -
4.0 MHz, 5.3 - 5.4 MHz, 7 - 7.3 MHz, 10.1 - 10.15 MHz, 14 - 14.2 MHz, 18.07 - 18.17 MHz, 21.0 - 21.4 MHz, 24.89 - 24.99 MHz,
28.0 - 29.7 MHz and 50.0 - 54.0 MHz.
Table 6
Compliant Cables and Accessories
The use of accessories and cables other than those specied or sold by EMS as replacement parts may result
in increased emissions or decreased immunity of this product.
CABLES AND
ACCESSORIES
MAXIMUM
LENGTH
COMPLIES WITH
Handpiece < 2.9 m CISPR 11 Class B / Group 1: RF electromagnetic disturbance
IEC 61000-4-2 Electrostatic discharge (ESD)
IEC 61000-4-3 Electromagnetic elds radiated by radio-frequencies
IEC 61000-4-4 Electric fast transient / burst
IEC 61000-4-5 Surge
IEC 61000-4-6 Disturbances induced by radio-frequency elds
IEC 61000-4-8 Power frequency magnetic eld (50/60 Hz)
IEC 61000-4-11 Voltage dips, short interruptions and voltage variations
Sector cord > 2.9 m
Table 7
Essential Performance
The DOLORCLAST
®
Radial Shock Waves has neither life sustaining functions nor diagnostic of life supporting functions.
The following functions are observed:
• Continuous work of pneumatic shocks,
• No changes of mode,
• No changes in set-values.
