Page #10 background image
3.2 Features
Table 1 describes the features available on the Mercury+ ST1 base board.
Feature Description
Form factor 120 × 100 mm
System features Built-in Xilinx JTAG (via USB connection)
Low-jitter clock generator
Programmable user oscillator (optional)
Memory microSD card holder
Connectors 2 × USB 3.0 connectors (host & device)
2 × RJ45 Gigabit Ethernet connectors
Micro USB (FTDI USB 2.0 High-Speed device controller)
Mini DisplayPort connector
SFP+ connector
FMC HPC connector
2 × MIPI D-PHY connectors (CSI , CSI/DSI)
HDMI 2.0 connector
User I/Os 2 × 40-pin Anios pin headers
3 × 12-pin IO connectors
2 × user push bottons
Supply voltage 12 V DC (internal, external)
Table 1: Base Board Features
Warning!
Please note that the available features depend on the equipped Mercury FPGA/SoC module.
3.3 Board Configuration and Product Codes
Table 2 describes the standard base board configuration. Custom configurations are available; please contact
Enclustra for further information.
Product Code Features Temperature Range
ME-ST1-W Refer to Table 1 -20..+75
C
Table 2: Standard Base Board Configuration
D-0000-456-001 10 / 48 Version 02, 23.07.2020
