3.8 Mechanical Data
Table 4 describes the mechanical characteristics of the Mercury+ ST1 base board. A 3D model (PDF) and a
STEP 3D model are available [6], [7].
Symbol Value
Size 120 × 100 mm
Component height top 11.3 mm
Component height bottom 8 mm plastic standoffs equipped on bottom side
Weight 100 g (without battery and module)
Table 4: Mechanical Data
3.9 Mechanical Components
Table 5 describes the mechanical components present on the Mercury+ ST1 base board. The listed elements
are for reference only. Any other components that meet the requirements may be used.
Product Number Manufacturer Description
973080365 Würth Elektronik 4 × plastic spacer bolt with female thread/clip, length 8 mm
Table 5: List of Mechanical Components
